CAMERA IP DAHUA PTZ 2MP IP66 Voir plus grand

SD59220I-HC CAMERA IP DAHUA PTZ 2MP IP66

Nouveau produit

HDCVI Speed Dôme – 2 Mpx – CMOS
Zoom : 20x ZO – 16x ZD – IR : 100M – Poids : 3.5Kg
Range : 0~360° endless (Pan)/-15~90°(Tilt : Auto Flip 180°)
Speed : 0.1-300º/S (Pan) – 0.1-200º/S(Tilt)
Preset : 400°/s (Pan); 300°/s (Tilt)
Protocols : DH-SD, Pelco-P/D (Auto recognition) BLC / HLC / DWDR

Plus de détails

SD59220I-HC

  • Model DH-SD59220I-HC
    Camera
    Image Sensor 1/2.8” Exmor CMOS
    Effective Pixels 1920(H) x 1080(V), 2Megapixels
    Horizontal Resolution ≥1000TVL
    Scanning System Progressive
    Electronic Shutter Speed 1/1 ~ 1/30,000s
    Min. Illumination More than 50dB
    25/30fps@1080P,25/30/50/60fps@720P More than 50dB
    Video Output 1-channel BNC HDCVI high definition video output
    Camera Features
    Day/Night Auto(ICR) / Color / B/W
    Backlight Compensation BLC / HLC / DWDR (Digital WDR)
    White Balance Auto, ATW, Indoor, Outdoor, Manual
    Gain Control Auto / Manual
    Noise Reduction 2D/3D
    Privacy Masking Up to 24 areas
    Digital Zoom 16x
    Lens
    Focal Length 4.7mm~94mm (20x Optical zoom)
    23x Optical zoom
    Max Aperture F1.4~ F2.6
    Focus Control Auto / Manual
    Angle of View H: 54.1° ~ 3.2°
    Close Focus Distance 100mm~1000mm
    PTZ
    Pan/Tilt Range Pan: 0° ~ 360° endless; Tilt: -15° ~ 90°, auto flip 180°
    Manual Control Speed Pan: 0.1° ~300° /s; Tilt: 0.1° ~200° /s
    Preset Speed Pan: 400° /s; Tilt: 300° /s
    Preset 300(DH-SD), 255(Pelco-P/D)
    PTZ Mode 5 Pattern, 8 Tour, Auto Pan, Auto Scan
    Speed Setup Human-oriented focal length/ speed adaptation
    Power up Action Auto restore to previous PTZ and lens status after power failure
    Idle Motion Activate Preset/ Pan/ Scan/ Tour/ Pattern if there is no command in the specified period
    Protocol DH-SD, Pelco-P/D (Auto recognition)
    IR Distance 100m
    Auxiliary Interface
    RS485 1 port
    Alarm 2/1 channel In/Out
    General
    Power Supply AC24V/ 3A (±10%)
    Power Consumption 12W, 25W (IR on)
    Working Environment -40ºC ~ 70ºC / Less than 90% RH
    Ingress Protection IP66
    Dimensions Φ186 (mm) x 310(mm)
    Weight 3.5Kg
