XVR5216AN-X DVR DAHUA 16 CHANNEL 2MP

Nouveau produit

16 Channel Penta-brid 1080P Digital Video Recorder

> H.265+/H.265 dual-stream video compression
> Supports HDCVI/AHD/TVI/CVBS/IP video inputs
> Max 24 channels IP camera inputs, each channel up to 6MP; Max 96Mbps Incoming Bandwidth
> Smart Search and Intelligent Video System

Plus de détails

XVR5216AN-X

  • System
    Main Processor Embedded Processor
    Operating System Embedded LINUX
    Video and Audio
    Analog Camera Input 16 Channel, BNC
    HDCVI Camera 5MP, 4MP, 1080P@25/30fps, 720P@50/60fps, 720P@25/30fps
    AHD Camera 5MP, 4MP, 1080P@25/30, 720P@25/30fps
    TVI Camera 5MP, 4MP, 1080P@25/30, 720P@25/30fps
    CVBS Camera PAL/NTSC
    IP Camera Input 16+8 Channel, each channel up to 6MP
    Audio In/Out 1/1, RCA
    Two-way Talk Reuse audio in/out, RCA
    Recording
    Compression H.265+/H.265/H.264+/H.264
    Resolution 5M-N, 4M-N, 1080P, 1080N, 720P, 960H, D1, CIF
    Record Rate Main stream:the 1st & 2nd channels 5M-N(1~10fps), other channels 4M-N/1080P(1~15fps); 1080N/720P/960H/

    D1/CIF (1~25/30fps)

    Sub stream: D1/CIF(1~15fps)
    Bit Rate 32Kbps ~ 6144Kbps Per Channel
    Record Mode Manual, Schedule (General, Continuous), MD (Video detection: Motion Detection, Video Loss, Tampering), Alarm, Stop
    Record Interval 1 ~ 60 min (default: 60 min), Pre-record: 1 ~ 30 sec, Post-record: 10 ~ 300 sec
    Audio Compression AAC(only for the 1st channel), G.711A, G.711U, PCM
    Audio Sample Rate 8KHz, 16 bit Per Channel
    Audio Bit Rate 64Kbps Per Channel
    Display
    Interface 1 HDMI ,1 VGA
    Resolution HDMI:3840×2160, 2560×1440, 1920×1080, 1280×1024,

    1280×720

    VGA: 1920×1080, 1280×1024, 1280×720
    Multi-screen Display When IP extension mode not enabled: 1/4/8/9/16

    When IP extension mode enabled: 1/4/8/9/16/25
    OSD Camera title, Time, Video loss, Camera lock, Motion detection, Recording
    Network
    Interface 1 RJ-45 Port (1000M)
    Network Function HTTP, HTTPS, TCP/IP, IPv4/IPv6, Wi-Fi, 3G/4G, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE,DDNS, FTP, Alarm Server, P2P,IP Search (Supports Dahua IP camera, DVR, NVS, etc.)
    Max. User Access 128 users
    Smart Phone iPhone, iPad, Android
    Interoperability ONVIF 16.12, CGI Conformant
