NVR DAHUA 16/32/64 CHANNEL 1.5U UP TP 12MP Voir plus grand

NVR5464-4KS2 NVR DAHUA 16/32/64 CHANNEL 1.5U UP TP 12MP

Nouveau produit

16/32/64Channel 1.5U 4K&H.265 Pro Network Video Recorder (V2.00)

> Smart H.265+/H.265/Smart H.264+/H.264/MJPEG
> Max 320Mbps Incoming Bandwidth
> Up to 12MP Resolution for Preview and Playback
> 2HDMI/2VGA simultaneous video output

Plus de détails

NVR5464-4KS2

  • Technical Specification
    System
    Main Processor Quad-core embedded processor
    Operating System Embedded LINUX
    Audio and Video
    IP Camera Input 16/32/64 Channel
    Two-way Talk 1 Channel Input, 2 Channel Output, RCA
    Display
    Interface 2 HDMI, 2 VGA
    Resolution HDMI1: 3840 × 2160 , 1920 × 1080 , 1280 × 1024,

    1280 × 720 , 1024 × 768
    VGA1: 1920 × 1080 , 1280 × 1024,

    1280 × 720 , 1024 × 768
    HDMI2/VGA2: 1920 × 1080
    Decoding Capability 4-ch@8MP(30fps), 16-ch@1080P(30fps)
    Multi-screen Display 1st Screen: 16CH: 1/4/8/9/16

    32CH: 1/4/8/9/16/25/36

    64CH: 1/4/8/9/16/25/36/64

    2nd Screen: 1/4/8/9/16
    OSD Camera title, Time, Camera lock, Motion detection, Recording
    Recording
    Compression Smart H.265+/H.265/Smart H.264+/H.264/MJPEG
    Resolution 12MP, 8MP, 6MP, 5MP, 4MP, 3MP, 1080P, 1.3MP, 720P, D1 etc.
    Bit Rate 16Kbps ~ 20Mbps Per Channel
    Record Mode Manual, Schedule (Regular, MD(Motion Detection) , Alarm, IVS), Stop
    Record Interval 1 ~ 120 min (default: 60 min), Pre-record: 1 ~ 30 sec, Post-record: 10 ~ 300 sec
    Video Detection and Alarm
    Trigger Events Recording, PTZ, Tour, Alarm Out, Video Push, Email, Snapshot, Buzzer and Screen Tips
    Video Detection Motion Detection, MD Zones: 396 (22 × 18), Video Loss and Tampering
    Alarm input 16 Channel
    Relay Output 6 Channel
    Playback and Backup
    Sync Playback 1/4/9/16
    Search Mode Time /Date, Alarm, MD and Exact Search (accurate to second)
    Playback Function Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Backup Selection, Digital Zoom
    Backup Mode USB Device/Network/eSATA Device
    Third-party Support
    Third-party Support Arecont Vision, Airlive, AXIS, Canon, Dynacolor, JVC, LG, Panasonic, Pelco, PSIA, Samsung, Sanyo, Sony, Watchnet and more
